Precision because of the scale of the data it is working with and as a When this happens, the graphics Engine has to scale toĪccommodate the large coordinate range and in some cases it runs out of Strange data miles away at 0,0 or again a large negative coordinate or Something that causes this, or you have data in one position and have some Points with millions in the negative - and it can be a block reference or That is visible (like 0 elevation data or in some cases a large negativeĮlevation data of some kind that came in from a CAD file - I have seen You have data at one elevation and you have something miles away vertically Project having data miles away from the place that you are working - either The problem with the surface disappearing is typically caused by your While I also believe that there is also something else causing a slow down - these two are a large part of what you may be seeing in TBC v5 You may also find that the shipped templates are read only - you can find the templates folder (support - options - File locations) and find the path shown in Project Templates in File Explorer - find the VCT files and then change their properties so they are not write protected - then you can overwrite them using Business Center - HCE with your preferred setting. I will update the shipped Project Templates this week and post updated ones
Change the settings and then Save as a Project Template. Again you can toggle that at the base of the screen or find those setting in Project Settings - View - Display Settings.
You should change the settings and save as a new Project Template so that new projects don't have this by defaultĢ) Toggle Line Markings is ON by default - I recommend that that should be OFF by default as you will get a lot of Blue ElevAtion Text after importing any 3D Lines from any source and that also can hog your graphics. This displays native cad linestyles like dashed lines as dashed lines and that can really slow down your graphics - the toggle is at the base of the V5 screen near Snaps and can also be found in Project Settings - View - Display Options This week I noticed that some of the project templates that shipped with v5 have the following settings set to ON or Off when in Business Center - HCE they were set to the opposite.ġ) Show All Lines as Solid is set to OFF when it should be ON for most construction Use Cases.
